No. | Description | Q'ty |
|---|
1 | Hard disk drive | 1 |
2 | Flat cable | 1 |
3 | Power cord | 1 |
4 | Screw | 2 |
| 5 | Inner cover | 1 |
| 6 | HDD cover | 1 |
