SP 330DN, SP 330SN, SP 330SFN, SP 3710DN, SP3710SF
Replacement and Adjustment
ADF/ARDF Unit (Only MF Models)
ARDF Unit (for Touch Panel Models)
ARDF Separation Pad
Open the ARDF top cover.
Remove the ARDF separation pad [A] (2 hooks, spring x 1).
