1. Open the top cover.
  2. Pull the front cover open lever (1), and open the front cover (2).

  3. Left cover [A] ( × 3, hook at the arrow mark below)

    • Top front screw: M3 x 8, others: M4 x 10
    • Remove the rear cover and the operation panel in advance when you meet difficulties in removing the left cover.
